18000BPH Plastic Drink Bottle Pure Water Washing Filling Capping Equipment

3-in-1 filling monoblock, combined with rinsing, filling and capping. It is innovated and designed in the requirement of still
pure water and mineral water, on the bases of introducing, digesting and absorbing advanced technology from Germany and Italy.
Quantity:
  • RFCW
  • FILLEX
  • 8422301090

Water Filling Machine

Water Filling Line Production Plant is one of advanced models which is our company combines international advanced self-filling process and technology developed specifically for mineral water, pure water and other non-gas beverage filling installation.


Features:

(1) This bottling machine is mainly used for washing, filling and capping PET bottle which can fill non- carbonated drinks suchas mineral water, pure water, wine and so on.
(2) Bottle washing, filling and capping are achieved in one filling machine.
(3) Fillex Filling machine adopts hanging type conveying-bottle structure to make changing bottle mold more convenient, faster and more laborsaving.

Water Filling Machine111

Technical Parameter:


Model

RFC-W 14-12-5

RFC-W16-16-5

RFC-W24-24-8

RFC-W32-32-8

RFC-W40-40-10

RFC-W50-50-15

RFC-W60-60-15

RFC-W72-72-18

Capacity

3,000-5,000bph

5,000-8,000bph

10,000-12,000bph

15,000bph

18,000bph

22,000-24,000bph

28000-30,000bph

36,000bph

Suitable

bottle

φ=50-110mm H=160 -310mm     200-2500ml PET bottles

Power

2.42kw

3.12kw

3.92kw

3.92kw

5.87kw

7.87kw

11.37kw

11.37kw

Dimension

2360x1770x2700

2760x2060x2700

2800x2230x2700

3550x2650x2700

4700x3320x2700

5900x4150x2700

5770x5290x2700

6540x4900x2700

Weight

2500kg

3500kg

3800kg

4200kg

5000kg

8500kg

11000kg

13000kg

Features:

Place & capping system. Automatic caps arranging, feeding.

Electromagnetic capping heads, with burden discharge function,

All 304stainless steel construction

No bottle no caps delivery.

Automatic stop when lack of bottle

微信图片_20201110082936


Workshop:

工厂1工厂2

FAQ:


Q1: Are you a trading company or a manufacturer?

A1: We have our own factory for many years,can give u best service.

Q2: What's your guarantee if we buy your machines?

A2: We offer you high quality machines with 1 year guarantee and free spare parts for 1 year. Meanwhile our engineers have rich experience and have gone to more than 50 countries for installation and commissioning.

Q3: When can I get my machine after I paid?

A3: We will deliver the machines on time as the date we agreed both side.

Q4: How can I install my machine when it arrives?

A4: Our engineer will go to your side as soon as you get your machines ready for testing and teaching your technicians how to run the machines.

Q5: What's the delivery time?

A5: 30-45 days after the T/T deposit or L/C.

Q6: Do you provide customized service?

A6: We can design the machines according to your requirements (material, power, filling type, container and etc), at the same time we will give you professional suggestion by many years industrial experience.
