Availability: | |
---|---|
Quantity: | |
CL-10R
FILLEX
Machine is with beautiful design, main frame is using high grade carbon steel, covering stainless steel, solid and free of corrosion. Uncovered parts are anti corrosion treated and sprayed with protective paint.
Large color touch screen containing machine parameters, production info, malfunction and other relative info. Friendly UI is easy to learn, with CN and EN language display, easy to switch. Need extra charge to provide other minority language UI.
Machine driving power is from German SEW reducer, steady and reliable.
Synchronous belt controlling infeed worm, easy to adjust.
Conveyor stand can apply to 82.6 width chain plate. Support side plate is using stainless steel plate with 3mm thickness. We can provide special format conveyor stand, need user to inform us of conveyor cross section size. We can’t provide chain plate.
Bottle type changing parts are using fast change design or won’t use any tools in the changing process, and using extremely short time. In the condition when operator is familiar with the parts, only need 10-15minutes to switch, increased production efficiency.
Bottle rotary table is using high grade alloy aluminum with spoke structure, ensures enough strength and utmost reduces self rotary inertia. It can easily change from maximum rotation speed to motionless. With advanced frequency convertor soft brake technology, it can utmost ensure mechanical structure from damage.
Complete monitoring system is all around the machine, they can feedback machine condition real time onto touch screen, operator can get info like production speed, capacity operating status and malfunction etc.
Machine is with manual and auto modes, when using auto mode, machine speed can change automatically with the whole production line, no need of manual operation. When using manual mode, operator can adjust machine speed any time, easy to operate.
Central lubrication system provide high grade lubrication for machine lubrication points, operator only need to pay attention to oil cup volume at lubrication system. For other lubrication points, we also provided detailed instruction and placed on machine surface.
Machine is with beautiful design, main frame is using high grade carbon steel, covering stainless steel, solid and free of corrosion. Uncovered parts are anti corrosion treated and sprayed with protective paint.
Large color touch screen containing machine parameters, production info, malfunction and other relative info. Friendly UI is easy to learn, with CN and EN language display, easy to switch. Need extra charge to provide other minority language UI.
Machine driving power is from German SEW reducer, steady and reliable.
Synchronous belt controlling infeed worm, easy to adjust.
Conveyor stand can apply to 82.6 width chain plate. Support side plate is using stainless steel plate with 3mm thickness. We can provide special format conveyor stand, need user to inform us of conveyor cross section size. We can’t provide chain plate.
Bottle type changing parts are using fast change design or won’t use any tools in the changing process, and using extremely short time. In the condition when operator is familiar with the parts, only need 10-15minutes to switch, increased production efficiency.
Bottle rotary table is using high grade alloy aluminum with spoke structure, ensures enough strength and utmost reduces self rotary inertia. It can easily change from maximum rotation speed to motionless. With advanced frequency convertor soft brake technology, it can utmost ensure mechanical structure from damage.
Complete monitoring system is all around the machine, they can feedback machine condition real time onto touch screen, operator can get info like production speed, capacity operating status and malfunction etc.
Machine is with manual and auto modes, when using auto mode, machine speed can change automatically with the whole production line, no need of manual operation. When using manual mode, operator can adjust machine speed any time, easy to operate.
Central lubrication system provide high grade lubrication for machine lubrication points, operator only need to pay attention to oil cup volume at lubrication system. For other lubrication points, we also provided detailed instruction and placed on machine surface.
Name | Fully automatic rotary cold glue labeling machine |
Model | CL-10R |
Main motor power | 3kw |
Main voltage | 380±10% V |
Frequency | 50 Hz |
Suitable for bottle type | ∮40~90,H=150~300 |
Maximum label width | 208mm |
Capacity | 6000-12000bph |
Dimension | 2340*2736.5*1990 |
Weight | 3500kg |
Compressed air | consumption0.08M3/min(pressure0.6Mpa;no oil) |
Consumption of label | ≤1‰ |
Name | Fully automatic rotary cold glue labeling machine |
Model | CL-10R |
Main motor power | 3kw |
Main voltage | 380±10% V |
Frequency | 50 Hz |
Suitable for bottle type | ∮40~90,H=150~300 |
Maximum label width | 208mm |
Capacity | 6000-12000bph |
Dimension | 2340*2736.5*1990 |
Weight | 3500kg |
Compressed air | consumption0.08M3/min(pressure0.6Mpa;no oil) |
Consumption of label | ≤1‰ |
[
This machine is used for using the Taiwan touching type of PLC control or knob control. It is made up of photo electricity equipment of Japan OMRON. Synchronization electrical, timing electrical, conveyor belt.
Import strap etc correlative part.
The design of mainframe part absorbed label transmit of import machine and solved the unsteady ingredient of homemade common label.
The machine is suitable for various specifications of bottles. Its operation is easy and it can be finished in a short time.
]
[
This machine is used for using the Taiwan touching type of PLC control or knob control. It is made up of photo electricity equipment of Japan OMRON. Synchronization electrical, timing electrical, conveyor belt.
Import strap etc correlative part.
The design of mainframe part absorbed label transmit of import machine and solved the unsteady ingredient of homemade common label.
The machine is suitable for various specifications of bottles. Its operation is easy and it can be finished in a short time.
]
