Vacuum Deaerating Machine

Quantity:
[

Vacuum Deaerating Machine

  The vacuum deaerator and degasser is specialized in removing small air bubble from liquid material, and improve quality of milk, juice and beverage. The material enters into inlet and forms thin umbrella shape, which enlarge available area, enforce small bubble separated and evacuated under vacuum negative pressure condition. To avoid active ingredient loss, a secondary steam saver makes the materials condensed and returned back to tank, which keep best flavor and good quality. Liquid level is automatically adjusted by level controller, and ensures enough volume left in tank.


]
[


Functions and features:

1. It can greatly shorten the exhaust time of the heating or cooling system after the first water injection, which is very beneficial to the initial commissioning of the system.

2. Remove the gas from the system to prevent air resistance and ensure the stability and reliability of the system during normal operation.
3. Eliminate pump cavitation and reduce system operating noise.
4. As the oxygen in the water is removed, the aerobic corrosion of the system will be reduced and the equipment life will be extended.

5. Because the gas in the water is removed, there will be no gas bubbles on the surface of the heat exchanger, which improves the heating efficiency.


Profile type

Single layer tank

Double jacket degasser

material

SS304 or SS316L

Capacity

1T/H-20T/H (Customized)

Pressure

Vacuum(0~-0.09Mpa)

Support Type

Vertical type

Structure

one layer

Inner layer+jacket

Cooling way

No

ice water /cooling water

Vacuum Pump

0.55KW-15KW

PARTS DETAILS

1.Pressure manhole

2.Various types of CIP cleaners

3.Glass Light

4.Adjustable Legs

5.Inlet and Outlet sanitary valve.

6.Thermometer (According to customer requirements ).

7.Liquid level meter and lever controller (According to customer requirements) .


]
[




]
[

Q1: Are you a trading company or a manufacturer?

A1: We have our own factory for many years, can give u best service.


Q2: What's your guarantee if we buy your machines?

A2: We offer you high-quality machines with a 1-year guarantee and free spare parts for 1 year. Meanwhile, our engineers have rich experience and have gone to more than 50 countries for installation and commissioning.


Q3: When can I get my machine after I paid?

A3: We will deliver the machines on time as the date we agreed on both sides.


Q4: How can I install my machine when it arrives?

A4: Our engineer will go to your side as soon as you get your machines ready for testing and teaching your technicians how to run the machines.


Q5: What's the delivery time?

A5: 30-45 days after the T/T deposit or L/C.


Q6: Do you provide customized service?

A6: We can design the machines according to your requirements (material, power, filling type, container and etc), at the same time we will give you professional suggestion by many years industrial experience.

]
