CO2 Carbonator

Quantity:
[

 Condition Milk/Juice Homogenizing Machine,7000L/h flow cream homogenize

Introduction:

The Raw material under the condition of continuous flow through the heat exchanger heating to 85 ~ 150 ℃(The temperature is adjustable). And at this temperature, keep a certain amount of time (several seconds) in order to achieve commercial asepsis level. QHS series drink mixer is designed and made for improving the proportion of water, syrup and carbonated dioxide. It adopts foreign advanced technology-static mixer to lighten water layer, increase carbonizing time, ensure mixing efficiency. Adopt carbon dioxide back flow deoxygenation, which can save carbon dioxide and deoxidize. High quality water pump and SEIMENS electrical equipment and other parts make up a complete automatic control system. It has coordinating action, beautiful appearance, convenient washing, high automatic level and other advantages. It is suitable for mixing all kinds of bottle, such as soda water, fruit juice, cola and other soft and hard drinks.




Model

QHS-1500

QHS-3000

QHS-4000

QHS-5000

QHS-6000

Production capacity

1000-2000

2500-3000

3500-4000

4500-5000

5500-6000

Adjustable proportion of of syrup and water

1:3-1:6

CO2 content

1.5-2.5

>2.5

>2.5

>3.5

>3.5

Cooling water entry temperature(℃)

0-5

Working pressure of carbonized and syrup tank(Mpa)

0.05-0.15

Working pressure of storage tank(Mpa)

0.2-0.5

Power(KW)

1.5

3.7

4.5

5.6

6.2

Dimension(mm)

900*700

*2000

1720*1140

*2100

1860*1300

*2100

2020*1500

*2200

2020*1500

*2200

Weight(KG)

500

1100

1300

1600

1800



]
[

1.Automatic with Alarm:The pressure in all tank and the liquid level of the machine are all controlled automatically with PLC.Once a error occurs,the alarm lamp will light and the alarm ring will sound and the mixer will stop automatically.
2.Easy operation and regulation:The operation of the mixer is especially convenient.Only turn around the buttons according to the pre-set program,the normal operation can be carried out.The production capacity,water-sugar proportion and gas content can be adjusted without exchanging and parts.
3.Even mixing and accurate proportion:One time mixing process is adopted,so the mixture is even.The mixing proportion of water and sugar is strictly controlled with measuring needle valve with fine regulation.Its precision can reach about 5%.
4.Enough gas content:The mixer adopts vacuum desoxidation technology at normal temperature.Its desoxidation ratio reaches above 90%.It has a baffle heat exchanger to cool the sugar-water mixture and carry out twice carbonating,So its carbon content is especially high.

]
[




]
[

Q1: Are you a trading company or a manufacturer?

A1: We have our own factory for many years, can give u best service.


Q2: What's your guarantee if we buy your machines?

A2: We offer you high-quality machines with a 1-year guarantee and free spare parts for 1 year. Meanwhile, our engineers have rich experience and have gone to more than 50 countries for installation and commissioning.


Q3: When can I get my machine after I paid?

A3: We will deliver the machines on time as the date we agreed on both sides.


Q4: How can I install my machine when it arrives?

A4: Our engineer will go to your side as soon as you get your machines ready for testing and teaching your technicians how to run the machines.


Q5: What's the delivery time?

A5: 30-45 days after the T/T deposit or L/C.


Q6: Do you provide customized service?

A6: We can design the machines according to your requirements (material, power, filling type, container and etc), at the same time we will give you professional suggestion by many years industrial experience.

]
