Semi Auto 5 Gallon Bottle Blowing Machine

  • MAXPET-S01-20L

1. Using PCL computer control, stable performance and simple operation;

2. Choose German Festo (FESTO) and Japanese SMC gas components;

3. Adopt energy-saving design, and the mechanical part has a compact and reasonable structure.

Machine specification

Clamping Force


Max.Clamping Stroke

330 mm

Max.Stretching Stroke

450 mm

Number of Cavities

1 Cavities

Theoretical Output

90 BPH

Max.mould Thickness

380 mm

Space Between Tie Bars

480*550 mm

Electrical System


380V/3PH/50HZ or Specail Order

Number of Heating Zone

4 Sections

Total power (full loaded)

60 Kw


Max.Container volume

25 L

Max.Diameter Range

65 mm

Max.Container Diameter

330 mm

Max.Container Height

550 mm

Auxiliary System

Low Pressure Air pressure

8-10 Bar

High Pressure Air pressure

30 Bar

Air Flow Rate


Dimension & WeightL*W*H

Bottle Molding Machine

195*80*210 CM


280*70*160 CM

Net Weight

1.5 Ton


Q1: Are you a trading company or a manufacturer?

A1: We have our own factory for many years,can give u best service.

Q2: What's your guarantee if we buy your machines?

A2: We offer you high quality machines with 1 year guarantee and free spare parts for 1 year. Meanwhile our engineers have rich experience and have gone to more than 50 countries for installation and commissioning.

Q3: When can I get my machine after I paid?

A3: We will deliver the machines on time as the date we agreed both side.

Q4: How can I install my machine when it arrives?

A4: Our engineer will go to your side as soon as you get your machines ready for testing and teaching your technicians how to run the machines.

Q5: What's the delivery time?

A5: 30-45 days after the T/T deposit or L/C.

Q6: Do you provide customized service?

A6: We can design the machines according to your requirements (material, power, filling type, container and etc), at the same time we will give you professional suggestion by many years industrial experience.
