SERVOPET-06-H
FILLEX
Production Description :
1.The servo motor is adopted to drive the molding mechanism, triggering off a bottom mold linkage as well. The whole mechanism works speedy, accurately, stably and flexibly. Meanwhile, it is energy efficient and environmental safe.
2.Oil or electricity heated, the mold can ensure bottles meet the hot filling requirement and withstand a temperature up to 90～95℃ without deformation. The capacity of each cavity can be up to 700~900bph.
3.The servo motor driven stepping unit and stretching mechanism have improved the speed, flexibility and accuracy of blowing.
4.The simple slide-in way of mold mounting makes it possible for the operators to change molds easily within 30 minutes.
5.The man-machine interface is highly automated and easy to operate. The compact machine occupies a smaller area.
6.The series is applied widely in PET hot filling bottle for juice, tea drinks, energy drinks and other hot filling drinks.
Technical Parameter :
Items | Unit | Model | |
SERVOPET-06-H | |||
Molding Spec. | Clamping force | kg | 48000 |
Clamping stroke | mm | 125 | |
Stretching stroke | mm | 240 | |
Bottom stroke | mm | 30 | |
Cavity pitch | mm | 76 | |
Number of cavities | cavities | 6 | |
Container Spec. | Max.volume, ctr. | L | 0.6 |
Neck diameter | mm | 18～38 | |
Max.diameter, ctr. | mm | 70 | |
Max.height, ctr. | mm | 240 | |
※※ | THEORETICAL OUTPUT | bph | Hot Fill Bottle:5000-6000 |
Power Spec. | Power Consumption | KW | 42 |
Heating Power | KW | 39 | |
Air Compressor Spec. | Blowing pressure | Kg/c㎡ | 35 |
High pressure air consumption | m3/min | 8 | |
Water Chilling Spec. | Operating pressure | Kg/c㎡ | ≥4 |
Temperature range | ℃ | 5~20 | |
Refrigerating capacity | kcal/hr | 12222 | |
Flow Rate | L/min | 70 | |
Water Cooling Spec. | Operating pressure | Kg/c㎡ | ≥4 |
Temperature range | ℃ | ≤30 | |
Flow Rate | L/min | 85 | |
Main Machine Spec. | Size(L*W*H) | mm | 4200*2050*2500 |
Weight | Kg | 5500 | |
Whole Set Spec. | Size(L*W*H) | mm | 4845*4420*2700 |
Weight | Kg | 6500 | |
