Tubular Type UHT Sterilizer

Quantity:
[

 Condition Milk/Juice Homogenizing Machine,7000L/h flow cream homogenize

1. Usage: Pipe sterilizer can take hot process on the dairy production, liquid foods beverage, concentrate jam, biology,

medicine etc. sterilizer of other model.

2. Main structure: Material tanks, sterilizer tank, material pump, exheater, hot water cross occur, controller etc.

3.Working principle: pre-sterilizing, sterilizing for the pipe which material will touch, use the hot water cycle in the pipe,

more than 20 min, then lower the pipe temp., starting sterilizing for the material. The material which had disposal to the

material tank, use the pump sending to pipe heat exchanger. Then put the material into heater pipe and sterilizing

according to require time, and after sterilizing to the keeping pipe, then into the cooling pipe and sending to the filling

machine



Model

UHT-T1000

UHT-T2000

UHT-T3000

UHT-T4000

UHT-T5000

UHT-T10000

Product capacity T/h

1

2

3

4

5

10

Heeat exchanging area (m2)

12

15

20

25

28

52

Sterilizing temperature(°C)

85-95

85-95

85-95

85-95

85-95

85-95

Warm keeping timeS

25

25

25

25

25

25


]
[

Sterilizer With the following advantage :

1. High heating efficiency , with 90% heat recovery system;

2. Low temperature gap between heating medium and product;

3. Highly automatic control system, auto control and record CIP cleaning system, self sterilize system, product sterilize system;

4. Accurate control sterilize temperature, auto control steam pressure, flow rate and product rate etc. ;

5. Product pipe wall use advanced technology for polishing and automatic welding , pipe can be self cleaned automatically, whole equipment self sterilize, which make sure whole system aseptic;

6. This system with high safety performance, all spare parts use good quality brand, and have pressure protect measurements and alarm system of steam, hot water and product etc.;

7. High reliability , use famous brand product pump, hot water pump, different type valve, control system electrical components;

8. Self CIP cleaning system;

]
[




]
[

Q1: Are you a trading company or a manufacturer?

A1: We have our own factory for many years, can give u best service.


Q2: What's your guarantee if we buy your machines?

A2: We offer you high-quality machines with a 1-year guarantee and free spare parts for 1 year. Meanwhile, our engineers have rich experience and have gone to more than 50 countries for installation and commissioning.


Q3: When can I get my machine after I paid?

A3: We will deliver the machines on time as the date we agreed on both sides.


Q4: How can I install my machine when it arrives?

A4: Our engineer will go to your side as soon as you get your machines ready for testing and teaching your technicians how to run the machines.


Q5: What's the delivery time?

A5: 30-45 days after the T/T deposit or L/C.


Q6: Do you provide customized service?

A6: We can design the machines according to your requirements (material, power, filling type, container and etc), at the same time we will give you professional suggestion by many years industrial experience.

]
