Plate Type UHT Sterilizer

Quantity:
[

 Condition Milk/Juice Homogenizing Machine,7000L/h flow cream homogenize

Introduction:

The Raw material under the condition of continuous flow through the heat exchanger heating to 85 ~ 150 ℃(The temperature is adjustable). And at this temperature, keep a certain amount of time (several seconds) in order to achieve commercial asepsis level. And then in the condition of sterile environment, it is filled in aseptic packaging container.The whole sterilization process is completed in a moment under high temperature, which will completely kill the microorganisms and spores which can cause corruption and deterioration. And as a result, the original flavor and nutrition of the food were greatly preserved. This strict processing technology effectively prevents the secondary contamination of food and greatly extends the shelf life of products.



We can manufacture and customize the Plate sterilizer according to the process and the requirment from customer with capacity from 20L to 50000L/hour.



Application:

Easyreal Company has manufacturered the advanced automatic plate type sterilizer Combined Italian technology and conform to Euro-standard. This Plate sterilizer is widely used for the natural fruit juice, tea drink, milk and other liquid products with relatively good fluidity.




Model

HM7000-25

HM7000-35

HM7000-60

Rated flow capacity

1000L/H-7000L/h

Max pressure

25Mpa

35Mpa

60Mpa

Rated working pressure

0-20Mpa

0-28Mpa

0-48Mpa

Motor power

55Kw

75Kw

132Kw

Number of Plunger

3

3

3

Pressure adjustment

Manual wheel adjustment, Hydraulic or Pneumatic adjustment available as option

Electric control cabinet

Provided as customer option

Frequency converter

Available as customer option

Feed pressure

0.2-0.3MPa

CIP

100°C/≤10000CP

Size

1.8*1.2*1.3(M)

1.8*1.2*1.3(M)

2.2*1.6*1.5(M)

Weight

3500kg

3800kg

5000kg

Shell material

SS 304

Material of sealing ring

X4310(Hemp fiber +Teflon)

Pressure gauge

Diaphragm type


]
[

Features:

1. Main structure is SUS 304 stainless steel.
2. Combined Italian technology and conform to Euro-standard.
3. Great heat exchange area, low energy consumption and easy maintenance.
4. Adopt mirror welding tech and keep the smooth pipe joint.
5. Auto backtrack if not enough sterilization.
6. Liquid level and temp controlled on real time.
7. CIP function.

8. Can be working together with homogenizer, Vacuum Deaerator and degasser and separator, etc.

9. Independent Siemens control system. Separate control panel, PLC and human machine interface.



Independent control system:

Realization of automatic control of material delivery and signal conversion.



The control system adheres to Easyreal's design philosophy:

1.  High degree of automation, minimize the number of operators on the production line.

2.  All electrical components are international first-class top brands, to ensure the stability and reliability of equipment operation;

3.  In the process of production, man-machine interface operation is adopted. The operation and state of the equipment are completed and displayed on the touch screen.

4.  The equipment adopts linkage control to automatically and intelligently respond to possible emergencies;



Suppliers and brands of components ofcontrol system:

Core and key electrical components are selected from international first-class brands, such as ABB button from Switzerland, Germany Siemens touch screen and PLC, Ddanmark DANFOSS frequency inverter, France SCHNEIDER low-voltage apparatus.


]
[




]
[

Q1: Are you a trading company or a manufacturer?

A1: We have our own factory for many years, can give u best service.


Q2: What's your guarantee if we buy your machines?

A2: We offer you high-quality machines with a 1-year guarantee and free spare parts for 1 year. Meanwhile, our engineers have rich experience and have gone to more than 50 countries for installation and commissioning.


Q3: When can I get my machine after I paid?

A3: We will deliver the machines on time as the date we agreed on both sides.


Q4: How can I install my machine when it arrives?

A4: Our engineer will go to your side as soon as you get your machines ready for testing and teaching your technicians how to run the machines.


Q5: What's the delivery time?

A5: 30-45 days after the T/T deposit or L/C.


Q6: Do you provide customized service?

A6: We can design the machines according to your requirements (material, power, filling type, container and etc), at the same time we will give you professional suggestion by many years industrial experience.

]
