Juice Homogenizer

Quantity:
[

 Condition Milk/Juice Homogenizing Machine,7000L/h flow cream homogenize

Working method

when product is flowing through the adjustable valve ,the particles or droplets present in mixed fluids with high pressure will be subdivided into the very smallest sizes (diameter Φ=0.1~0.2 um, average Φ ≤1um ) because of pressure decrease, expansion, explosion,cutting and high-speed impacting etc., then the emulsions or dispersions could be produced.Through homogenizing the stability, easy-absorb, long-life, taste and color etc. of product could be realized.


Main applications:
(1) cell disruption, process new products, or harvesting the intracellular products;
(2) subdividing the particles or droplets present in fluids into very smallest sizes (submicron) and creating a stable dispersions and emulsions;
(3) homogenizing many other products;

Widely applied in fields of food, genetic engineering, chemical industry, pharmacy etc..


Model

HM7000-25

HM7000-35

HM7000-60

Rated flow capacity

1000L/H-7000L/h

Max pressure

25Mpa

35Mpa

60Mpa

Rated working pressure

0-20Mpa

0-28Mpa

0-48Mpa

Motor power

55Kw

75Kw

132Kw

Number of Plunger

3

3

3

Pressure adjustment

Manual wheel adjustment, Hydraulic or Pneumatic adjustment available as option

Electric control cabinet

Provided as customer option

Frequency converter

Available as customer option

Feed pressure

0.2-0.3MPa

CIP

100°C/≤10000CP

Size

1.8*1.2*1.3(M)

1.8*1.2*1.3(M)

2.2*1.6*1.5(M)

Weight

3500kg

3800kg

5000kg

Shell material

SS 304

Material of sealing ring

X4310(Hemp fiber +Teflon)

Pressure gauge

Diaphragm type


]
[

Power End

1).Electric motor,Siemens/Abb three-phase asynchronous motor,ranging from 3-160KW for various models.
2). Gearbox,two stage transmission.
Using two-stage reducing. First stage is V-belt reducing,and second stage adopts herring bone gear for symmetrical transmission,with diamountable slides. Special alloy rolling bearings and bushes at the two sides don’t need to be changed if under normal operation.
Horizontal structure,stable, low noise, mechanical efficiency is increased by about 10% on average.
Combined splash system lubrication and oil pump water cooling auxiliary lubrication ensure high quality lubricating.

Liquid End

1.Check valve
The conical type check valve can be applicable for the most product materials.
Valve can be offered with various materials according to customer’s product material properties,to realize the best working condition and meet CIP cleaning and acid and alkali resistant requirements especially in medical,dairy and chemical industry.
Poppet valve or ball valve. Ball valve offered for high viscocity liquid materials processing so as to ensure sufficient flow and stable working.
2.Homogenizing valve
Made of Tungsten-Cobalt-Titanium alloy or erosion-resisting cemented carbide,anti abrasion and compact,applicable for 0-1000bar pressure.
Optional for product materials and production requirements.
3.Sealing
Made of the 4th high grade sealing materials,anti-pressure,anti-abrasion and sanitary,heat resistance(up to 150℃).
V belts or square belts can be optional for product material properties,or customized belts can be offered.

4.Plunger
Made of erosion-resistance stainless steel,treated through multiple processes(reach mirror surface effect),accurate and durable. The application practice in dairy industry has proves that the average use life can reach 6000-10000 hours.


]
[




]
[

Q1: Are you a trading company or a manufacturer?

A1: We have our own factory for many years, can give u best service.


Q2: What's your guarantee if we buy your machines?

A2: We offer you high-quality machines with a 1-year guarantee and free spare parts for 1 year. Meanwhile, our engineers have rich experience and have gone to more than 50 countries for installation and commissioning.


Q3: When can I get my machine after I paid?

A3: We will deliver the machines on time as the date we agreed on both sides.


Q4: How can I install my machine when it arrives?

A4: Our engineer will go to your side as soon as you get your machines ready for testing and teaching your technicians how to run the machines.


Q5: What's the delivery time?

A5: 30-45 days after the T/T deposit or L/C.


Q6: Do you provide customized service?

A6: We can design the machines according to your requirements (material, power, filling type, container and etc), at the same time we will give you professional suggestion by many years industrial experience.

]
